Esquire Technologies Uninterruptible Power Supply

1 to 32 of 32 items

Page 1

Stock Code: 5PX3000IRT2UG2

Eaton 5PX GEN2 3000VA Rack Mount Line Interactive Uninterruptible Power Supply- Output power capacity - 3000W / 3000VA, Nominal Input and Output Voltage: 230V, 8x IEC 320 C13 and 2x C19 Outlets, Automatic Voltage Regulation (AVR),LCD Display For Real-Time Status And Measurements, Slot For Optional Network Management Card, 2U Rack/towerSingle Phase Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Product Overview
The new Eaton 5PX Gen2 UPS provides Enterprise Networks and Edge IT equipment with best-in-class line-interactive power protection maximising IT space and Service Continuity. Eaton 5PX Gen 2 offers powerful tools to remotely monitor, integrate with IT architecture and remotely deploy / maintain large installed base of UPSs.The innovative graphical LCD display makes configuration of the 5PX Gen2 easy and intuitive. The UPS offers an easy start-up configuration wizard to simplify your UPS setup process. Remote management and firmware upgrades are available with the optional Eaton Gigabit network management card. Advanced battery management and hot-swappable battery enables ease of maintenance and flexibility.

Highlights
Line-Interactive Uninterruptible Power Supply
2U Rackmount or Tower Single Phase
Output Power Capacity: 3000Watts/3000VA
Output Connections: (8) IEC 320 C13 And (2) IEC 320 C19
Nominal Input And Output Voltage: 230V
Input Connection: IC-320 C20
Topology: Line-Interactive
Automatic Voltage Regulation (AVR)
LCD display for real-time status and measurements
Slot for optional Network management card

Specifications
•Stock Code 5PX3000IRT2UG2
•Description Eaton 5PX GEN2 3000VA Rack Mount Line Interactive Uninterruptible Power Supply
•Product Type Line-Interactive UPS
•Form Factor Tower, Rackmount
•Unit Height 2U
•Volt-Amps (VA) 3000 VA
•Output Watts (W) 3000 W
•Number Of Outlets/Sockets 10
•Outlet/Socket Type C13, C19
•Secondary Frequency – Max 60 Hz
•Output Waveform Sine Wave
•Max Number Of Battery Packs 4
•Wattage 3000 W
•Output Power Factor 1
•Input Voltage – Min 150 V
•Output Voltage – Max 240 V
•Secondary Frequency – Min 50 Hz
•Battery Type Lead-Acid Maintenance-Free (Replaceable)
•Dimensions L/Dx H x W 603mmx 85.5mmx438 mm
•Weight 31.7 Kg

PDF Document

Stock Code: 5PX2200IRT2UG2

Eaton 5PX GEN2 2200VA Rack Mount Line Interactive Uninterruptible Power Supply- Output power capacity - 2200W / 2200VA, Nominal Input and Output Voltage: 230V, 8x IEC 320 C13 and 2x C19 Outlets, Automatic Voltage Regulation (AVR),LCD Display For Real-Time Status And Measurements, Slot For Optional Network Management Card, 2U Rack/tower Single Phase UPS, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Highlights
Line-Interactive Uninterruptible Power Supply
2U Rackmount or Tower
Output Power Capacity: 2200Watts/2200VA
Output Connections: (8) IEC 320 C13 And (2) IEC 320 C19
Nominal Input And Output Voltage: 230V
Input Connection: IC-320 C20
Topology: Line-Interactive
Automatic Voltage Regulation (AVR)
LCD display for real-time status and measurements
Slot for optional Network management card

Specifications
•Stock Code 5PX2200IRT2UG2
•Description Eaton 5PX GEN2 2200VA Rack Mount Line Interactive Uninterruptible Power Supply
•Product Type Line-Interactive UPS
•Form Factor Tower, Rackmount
•Unit Height 2U
•Volt-Amps (VA) 2200 VA
•Output Watts (W) 2200 W
•Number Of Outlets/Sockets 10
•Outlet/Socket Type C13, C19
•Secondary Frequency – Max 60 Hz
•Output Waveform Sine Wave
•Max Number Of Battery Packs 4
•Wattage 2200W
•Output Power Factor 1
•Input Voltage – Min 150 V
•Output Voltage – Max 240 V
•Secondary Frequency – Min 50 Hz
•Battery Type Lead-Acid Maintenance-Free (Replaceable)
•Dimensions L/Dx H x W 603mmx 85.5mmx438 mm
•Weight 31.7 Kg

PDF Document

Stock Code: SOLUE25100

Solarix Ultra Energy 25.6V 100 Ah LiFePo4 Single Battery Module- Normal Voltage 25.6V, Rated Capacity: 100Ah, Total Usable Energy 2.56KWh, Voltage Range 21.6V to 28.0V, Charge Current 26A , Discharge Current 50A. 19 inch Rack Mount Chassis, Design To Work Perfectly Hybrid Invertors Up To 3.5KVA 24V, Colour Black , Retail Box , 6 month Warranty

Click Here For More Detail

Click Here For a Quick Description

Product Overview
The Solarix Ultra Energy 25.6V 100 Ah LiFePo4 Single Battery Module is perfect for an entry level small to medium residential installation with a Lithium-ion battery solution with proven Lithium Iron Phosphate (LifePO4) chemical composition and great performance. Design To Work Perfectly with Hybrid Invertors Up To 3.5KVA 24V. Standard 19-Inch Rack Mount Embedded designed module for installation and maintenance.

Please Note This is unit is designed for single use installation and cannot be daisy chained

Highlights
• Ultra Energy 25.6 V 100 Ah Lithium Iron Phosphate (Lifepo4) Battery Module
• Design To Work Perfectly Hybrid Invertors Up To 3.5KVA 24V
• Battery Cycle Life ≥ 3000 @ 80% DOD, 23°C A
• Normal Voltage 25.6V
• Rated Capacity: 100Ah
• Total Usable Energy 2.56KWh
• Voltage Range 21.6V to 28.0V
• Charge Current 26A
• Discharge Current 50A
• Easy To Install 19 Inch Rack Mount Chassis
• Single Use Installation Battery Module- Cannot Be Daisy Chained

Specifications
• Stock Code SOLUE25100
• Description Solarix Ultra Energy 25.6 v 100 Ah LiFePo4 Single Battery Module
• Battery Type: Lithium Iron Phosphate (LifePO4) Chemical Composition
• 19 Inch Rack Mount Modular Design
• Total Usable Energy 2.56KWh
• Rated Capacity: 100Ah
• Battery Cycle Life ≥ 3000 @ 80% DOD, 23°C A
• Built In Protection For Over-Charge, Over-Discharge & Over-Temperature.
• Dimensions 497 x237x423 mm
• Weight 31kg
• Colour Black

Stock Code: 9E3000I

Eaton 9E3000I 3000VA/1600W Tower Online double conversion USB UPS, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

EATON 9E3000I 3000VA/1600W Tower Online double conversion USB UPS, Retail Box , 1 year Limited Warranty

Specifications
• Product Code: 9E3000I
• Description: EATON 9E3000I 3000VA/1600W Tower Online double conversion USB UPS

Electrical Input
• Connection: (1) IEC-320-C20
• Input Voltage Range: 176-300V without derating (up to 100-300V with derating)
• Nominal Voltag:e 208/220/230/240V
• Frequency: 50/60 Hz autoselection
• Frequency Range: 40-70 Hz

Electrical Output
• Voltages: 208V*/220V/230V/240V ±1%
• Voltage THD: <2% for 100% linear load
• Outlets: (6) IEC-320-C13, (1) IEC-320-C19
• Overload Capacity: 105%-130% : 60s, 130%-150% : 10s,>150% : ≥ 300ms
• Efficiency (Normal Mode): Up to 91% in Online mode
• Output Frequency: 50/60 Hz autoselect

Communications
• Communication Ports: 1 USB port + 1 RS232 serial port (USB and RS232 ports cannot be used simultaneously)
• Communication Slot: 1 slot for Network-M2, ModBus-MS or Relay-MS cards
• Power Management Software: Intelligent Power Editions

General
• Topology: Online double conversion
• Configuration: Tower
• Rating (VA/Watts): 3000/2400
• Dimensions (H x W x D, mm): 399 x 330 x 190
• Weight (kg): 24.2

Environmental & Standards
• Audible Noise: <37 dB @ typical load
• Operating Temperature: 0 to 40°C
• Safety markings: IEC/EN 62040-1
• EMC Markings: IEC/EN 62040 -2
• Approvals: CE, CB report (TUV)

Stock Code: 5PX1000IRT2UG2

Eaton 5PX GEN2 1000VA Rack Mount Line Interactive Uninterruptible Power Supply- Output Power Capacity - 1000W / 1000VA, Nominal Input and Output Voltage: 230V, 8x IEC C13 Output Connections, Automatic Voltage Regulation (AVR),LCD Display For Real-Time Status And Measurements, Slot For Optional Network Management Card, 2U Rack/tower Single Phase UPS, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Highlights
-Single Phase Line-Interactive Uninterruptible Power Supply
-2U Rackmount or Tower
-Output Power Capacity: 1000Watts/1000VA
-Input Connections 1x IEC C14 (10A)
-Output Connections: 8 x IEC C13 (10A)
-Nominal Input And Output Voltage: 230V
-Topology: Line-Interactive
-Automatic Voltage Regulation (AVR)
-LCD display for real-time status and measurements
-Slot for optional Network management card

Specifications
•Stock Code 5PX1000IRT2UG2
•Description Eaton 5PX GEN2 1000VA Rack Mount Line Interactive Uninterruptible Power Supply
•Product Type Single Phase Line-Interactive UPS
•Form Factor Tower, Rackmount
•Unit Height 2U
•Volt-Amps (VA) 1000 VA
•Output Watts (W) 1000w
•Outlet/Socket Type C13 x 8
•Secondary Frequency – Max 50 Hz
•Output Waveform Sine Wave
•Input Voltage – Min 150 V
•Output Voltage – Max 240 V
•Secondary Frequency – Min 50 Hz
•Battery Type Lead-Acid Maintenance-Free (Replaceable)
•Dimensions L/Dx H x W 603mmx 85.5mmx438 mm
•Weight 31.7 Kg

PDF Document

Stock Code: SKV7KVA

Solarix Skyking 7KVA 48V Hybrid Inverter - 7KW 48V SkyKing Hybrid Off-Grid Inverter,is integrated with a 80A MPPT solar charge controller, Retail Box , No warranty

Click Here For More Detail

Click Here For a Quick Description

Solarix Skyking 7KVA 48V Hybrid Inverter - 7KW 48V SkyKing Hybrid Off-Grid Inverter, is integrated with a 80A MPPT solar charge controller, Retail Box , No warranty

Product Overview

This is a multi-function inverter/charger, combining functions of inverter, solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.

Features

• Pure sine wave inverter

• Configurable input voltage range for home appliances and personal computers via LCD setting

• Configurable battery charging current based on applications via LCD setting Configurable AC/Solar Charger priority via LCD setting

• Compatible to mains voltage or generator power

• Auto restart while AC is recovering

• Overload/ Over temperature/ short circuit protection Smart battery charger design for optimized battery performance

• Cold start function

Specifications

• Stock Code: SKV7KVA

• Description: Solarix Skyking 7KVA 48V Hybrid Inverter

• Colour: Blue & Black

• Operating temperature range: 0-55°C

Inverter Mode

• Rated Power: 7000VA(5500W)

• DC INPUT: 48VDC, 127A

• AC OutputL: 230VAC, 550/60Hz, 23,90A, 1

• AC Input: 230VAC, 50/60Hz, 38.5A, 1

• DC Output: 54VDC

• Max.80A, Default 30A

• AC Output: 230VAC, 50/60Hz, 23.9A, 1

Charger Solar Mode:

• Rated Power: 6000W

• MAx Charger: 110A

• Nominal Operation Voltage: 240VDC

• Max Solar Voltage (VOC): 500VDC

• MPPT Voltage range: 120 - 450VDC

• Ingress Protection: IP21

• Protective class: class 1

Stock Code: 9E2000I

Eaton 9E2000I 2000VA/1600W Tower Online double conversion USB UPS, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

EATON 9E2000I 2000VA/1600W Tower Online double conversion USB UPS, Retail Box , 1 year Limited Warranty

Specifications
• Product Code: 9E2000I
• Description: EATON 9E2000I 2000VA/1600W Tower Online double conversion USB UPS

General
• Topology: Online double conversion
• Configuration: Tower
• Part Number: 9E2000I
• Rating (VA/Watts): 2000/1600
• Dimensions (H x W x D, mm): 399 x 330 x 190
• Weight (kg): 22.4

Electrical Input
• Connection: (1) IEC-320-C14
• Input Voltage Range: 176-300V without derating (up to 100-300V with derating)
• Nominal Voltage: 208/220/230/240V
• Frequency: 50/60 Hz autoselection
• Frequency Range: 40-70 Hz

Electrical Output
• Voltages: 208V*/220V/230V/240V ±1%
• Voltage THD: <2% for 100% linear load
• Outlets: (6) IEC-320-C13
• Overload Capacity: 105%-130% : 60s, 130%-150% : 10s,>150% : ≥ 300ms
• Efficiency (Normal Mode): Up to 91% in Online mode
• Output Frequency: 50/60 Hz autoselect

Stock Code: SKG5KA

Solarix Skyking 5KVA 48V Hybrid Inverter – Pure Sine Wave Transformerless Hybrid Off-Grid Solar Inverter Integrated With A 80A MPPT Solar Charge Controller, Design To Provide Reliable Power, Retail Box , No Warranty

Click Here For More Detail

Click Here For a Quick Description

Product Overview

The latest Solarix Skyking Branded 5KVA 48V Hybrid Inverter is designed to provide a reliable backup power solution for homes and small business office environment installations. Equipped with a 80A MPPT solar charge controller to maximize and regulate DC power from the solar array for charging the battery bank. Transformerless design provides reliable power conversion in compact size. The pure sine wave output enables easy startups for motor-type loads such as refrigerators, motors, pumps. compressors and laser printers as well as electronic loads like TVs. Computers. power tool and battery chargers. Does not support three phase and can only be used as single inverter. Batteries And Solar Panels Are Not Included.

Features

• Pure Sine Wave 48V Hybrid Inverter Rated Power: 5000W
• Transformerless Hybrid Off-Grid Solar Inverter
• Built-In 80A MPPT Solar Charge Controller
• Voltage: 230V AC and Battery Voltage: 48VDC
• Built-In Battery Equalization Function To Extend Battery Life Cycle
• Selectable Input Voltage Range For Home Appliances And Personal Computers
• Selectable Charging Current Based On Applications
• Configurable Ac/Solar Input Priority Via LCD Setting
• Compatible To Mains Voltage Or Generator Power
• Battery Equalization For Optimized Battery Performance And Lifecycle
• Overload And Short Circuit Protection
• Does Not Support Three Phase And Can Only Be Used As Single Inverter
• Batteries And Solar Panels Are Not Included

• Output power factor 1.0

• Programmable supply priority for PV ,battery or Grid

• User-adjustable charge current and voltage

• Wide PV input range (120Vdc -500Vdc),110A MPPT SCC

• Working without batteries in sunny day

• WiFi Monitoring Function (optional)

• Anti-dusk kit for harsh environment(optional)

• LCD remote control with 10 meters wire(optional)

• PV and electricity complementary

• Use with lithium batteries

Specifications

• Stock Code: SKG5KA

• Description: Solarix Skyking 5kva 48v Hybrid Inverter

• Product Type: Pure Sine Wave Transformerless Hybrid Off-Grid Solar Inverter

• Built-In 80A MPPT Solar Charge Controller
• Voltage: 230V AC and Battery Voltage: 48VDC
• Frequency Range: 50 Hz/60 Hz (Auto sensing),
• Transfer Time: 10 ms (For Personal Computers), 20 ms (For Home Appliances)
• Efficiency: 90-93%
• Cold Start Function
• Short Circuit Protection
• Selectable Charger Current Configurable AC/Solar
• Charge Priority Mains or Generator
• Power Overload/Over Temp Protection
• Smart Charge for Optimized Performance
• Does Not Support Three Phase And Can Only Be Used As Single Inverter
• Batteries And Solar Panels Are Not Included

• Color: Silver and Black

• Operating Temperature Range:0-55°C

Stock Code: ELP1600IEC

Eaton Ellipse PRO 1600VA/1000W Tower Line-interactive (AVR with booster + fader) UPS, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Eaton Ellipse PRO 1600VA/1000W Tower Line-interactive (AVR with booster fader) UPS, Retail Box , 1 year Limited Warranty

Overview
Product Description
The Eaton Ellipse PRO 1600, 1600VA, is a line interactive UPS specifically developed to protect workstations running demanding applications. The Ellipse PRO features a LCD display for real time status and measurements, 8 outlets ( 4 with battery backup and lightning protection and 4 with lightning protection. This unit includes Eco Control power outlets, which enable energy savings up to 20 percent and Advanced Surge Reduction (ASR) that complies fully with the requirements of the IEC 616431-1 standard. This UPS can be either placed as a tower, in a rack or be wall mounted.

Specifications:

Eaton Ellipse PRO 1600 – UPS – 1000 Watt – 1600 VA
Device Type: UPS – external
Rack Size: 19″ – 2U
Weight: 11.3 kg
Input Voltage: AC 230 V
Output Voltage: AC 220/230/240 V 15% / – 20%
Power Capacity: 1000 Watt / 1600 VA
Input Connectors: 1 x power IEC 60320 C14
Output connectors: 4 x power IEC 60320 C13 (UPS and surge) ¦ 4 x power IEC 60320 C13 (surge)
Battery: Lead Acid – 9 Ah
Batteries Qty: 2
Run Time (Up To): 9 min at half load
Networking: USB
Dimensions (WxDxH): 8.2 cm x 39 cm x 27.5 cm

Stock Code: 9E1000I

Eaton 9E1000I 1000VA/800W Tower Online double conversion USB UPS, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

EATON 9E1000I 1000VA/800W Tower Online double conversion USB UPS, Retail Box , 1 year Limited Warranty

Specifications
• Product Code: 9E1000I
• Description: EATON 9E1000I 1000VA/800W Tower Online double conversion USB UPS

General
• Topology: Online double conversion
• Configuration: Tower
• Part Number: 9E1000I
• Rating (VA/Watts): 1000/800
• Dimensions (H x W x D, mm): 356 x 228 x 144
• Weight (kg): 9.5

Electrical Output
• Voltages: 208V*/220V/230V/240V ±1%
• Voltage THD: <2% for 100% linear load
• Outlets: (4) IEC-320-C13
• Overload Capacity: 105%-130% : 60s, 130%-150% : 10s,>150% : ≥ 300ms
• Efficiency (Normal Mode): Up to 91% in Online mode
• Output Frequency: 50/60 Hz autoselect

Stock Code: RT2KVA

Nova Mercury 2KVA 1800 Watts Long Run Online UPS Pure Sine Wave UPS- Online, Double Conversion Pure Sine Wave Unit, Input Power Factor 0.99 (With PFC), 4 x 12V/7AH Batteries included , 50Hz Frequency, Generator Compatible, Emergency Power Off Function (EPO), Recharge time to 90% 4-6 hours, Single Phase With Ground, Retail Box , 6 month Warranty on Batteries

Click Here For More Detail

Click Here For a Quick Description

Product Overview
The Nova Mercury 2KVA (2000VA) 1800 Watts On-Line, Double Conversion, Pure Sine Wave UPS system is a high frequency (transformer less), On-Line, double conversion, pure sine wave unit. This is the ideal solution for your data centre and server rooms; PC’s and laptops; communications/telecom systems; automatic control systems and all other critical electronic systems. Superior input voltage window for energy saving (ECO mode). Mimic LCD display with multifunction parameter settings and operational status,Single Phase With Ground, Support generator input, Cold start function is built-in, 3-level intelligent charging modes, Output power factor 0.9, Colour Black

Specifications
• Stock Code RT2KVA
• Description Nova Mercury Long Run 2KVA 1800 Watts Online UPS Pure Sine Wave UPS
• Product Type 2000VA / 1600w Online, Double Conversion Pure Sine Wave Unit
• Single Phase With Ground
• Wide Input Voltage Range
• Input Power Factor 0.99 (With PFC)
• Output Power Factor 0.9
• Frequency range 40Hz - 70Hz (auto detect)
• Voltage regulation +-1%
• Frequency range(Utility. mode) 47-53Hz(for 50Hz) or 57-63Hz(for 60Hz)
• Frequency range(batt. mode) 50/60Hz+-0.01Hz
• Crest factor 0.125694444444444
• THDv <3% with linear load, <6% with non-linear load
• Waveform Pure Sinewave
• Emergency Power Off Function (EPO)
• ECO Mode Operation For Energy Saving (ECO)
• Generator Compatible
• SNMP / USB / RS232 Multiple Communications
• Smart Battery Charging Design For Optimized Battery Performance
• Recharge time to 90% 4-6 hours
• 4 x 12V/7AH Batteries included
• Ideal Solution For Data Centres And Server Rooms; PC’s And Laptops; Communications/Telecom Systems
• Colour Black
• Standard Dimension (WxHxD) 144x209x399
• Weight 17 (kg)

Suitable Environments/Applications
•Telecommunications
•Security industry
•Server rooms
•Data centres
•Medical sector
•Audio visual sector
•Retail sector
•SME sector

Stock Code: EG004PB

Solarix Power Storage Box - Modified Sine Wave, Rated Power 500w, 1x12V Sealed Lead Acid Battery 50Ah, AC Output Voltage 220V, 3x DC Output 12V/3A , 4x USB 5V Outputs 1x 12V Car Boost Start Jumper Output , Net Weight 12kg, Colour White , Retail Box , 6 month Warranty

Click Here For More Detail

Click Here For a Quick Description

Solarix Power Storage Box- Modified Sine Wave, Rated Power 500w, 1x12V Sealed Lead Acid Battery 50Ah, AC Output Voltage 220V, 3x DC Output 12V/3A , 4x USB 5V Outputs 1x 12V Car Boost Start Jumper Output , Net Weight 12kg, Colour White , Retail Box , 6 Months Warranty

Product Overview

The Solarix Power Storage Box is the latest product designed especially for load shedding to keep your electronic and electrical devices running during power outages, it equipped with a number of outputs allowing you to power up what you need to and stay connected for about 15 hours with some of the devices connected to this power storage box with a rechargeable 12V Sealed Lead Acid Battery 50Ah that is included, It is ideal for use on Laptops Computers, LED lights, Electrical fans and also provide power backup to all types of DC power equipment such as Routers , Modems , Decoders , VOIP Phone Systems , Surveillance System, Alarm System And Many Critical Telecommunications Equipment. The USB ports can be used to charge or power up Mobile Phones, Tablets, Cameras, Portable Speakers Etc. This unit can be charged through a standard AC outlet or with Solar panels connected to the device. It is perfect for power outages, home emergencies, outdoor activities, picnics, field parties, parades, road trips, camping, boating, urban markets, beach days, emergency relief and rescue, etc.

Please Note: Solar panels are not included with this package and must be purchased separately

Highlights

• Solarix Power Storage Box 500w

• Modified Sine Wave

• 1x Rechargeable 12V Sealed Lead Acid Battery 50Ah

• 1x AC Output Voltage 220V Rated Power 500w

• AC Output Frequency 50Hz

• 3x DC 12V with 36W Power Outputs

• 4x USB 5V outputs (1.0A x2 / 2.1A x2)

• 1x 12V Automotive Jumper Station

• LCD Display Battery Capacity, Battery Voltage

• LED Indicator USB Output Status, AC Charge Status

• 1x AC / DC 14.4V 5A Charging Adaptor Included

• 1x DC LED Light Included

• 1x Car Jumper Lead Included

• Built- In Carry Convenient Carry Handle

Stock Code: KSW3500VA3000W

Solarix KingStar 3.5KVA Hybrid Inverter - 3.5KW 24V KingStar Hybrid Off-Grid Inverter, Retail Box , No warranty

Click Here For More Detail

Click Here For a Quick Description

Solarix KingStar 3.5KVA Hybrid Inverter - 3.5KW 24V KingStar Hybrid Off-Grid Inverter, Retail Box , No warranty

Product Overview

The Solarix KingStar 3.5KVA Hybrid Inverter is a multi-function inverter/charger, combining functions of inverter, solar charger and battery charger to offer uninterruptible power support with portable size. lts comprehensive LCD display offers user-configurable acceptable and .easy-accessible button operation such as battery charging current.AC/solar charger priority, and acceptable input voltage based on different applications.

Features
• Pure Sine Wave Hybrid Inverter
• Configurable Input Voltage Range For Home Appliances And Personal Computers Via LCD Setting
• Configurable Battery Charging Current Based On Applications Via LCD Setting
• Configurable AC Solar Charger Priority Via LCD Setting
• Compatible To Mains Voltage Or Generator Power
• Auto Restart While AC Is Recovering
• Overload/Over Temperature/Short Circuit Protection
• Smart Battery Charger Design For Optimized Battery Performance
• Cold Start Function

Specifications
• Stock Code: KSW3500VA3000W
• Description: Solarix Kingstar 3.5kva Hybrid Inverter
• Pure Sine Wave Inverter Model:Ksw-3500va/3000w
• Input:220VAC 50/60hz
• Output:220VAC 50/60hz
• Dc Input:24VDC
• N.W: 19.06 kg
• G.W: 20.32 kg
• Packing Size: 565*383*188mm

Stock Code: ELP850IEC

Eaton Ellipse PRO 850VA/510W Tower Line-interactive (AVR with booster + fader) UPS, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Eaton Ellipse PRO 850VA/510W Tower Line-interactive (AVR with booster fader) UPS, Retail Box , 1 year Limited Warranty

SPECIAL FEATURES

Convenient extra-flat design for easy installation in any office environment Automatic Voltage Regulation (AVR) High performance surge-protection device compliant with IEC 61643-11 standard Data line protection to ensure that the internet line (including DSL) is protected against surges LCD display for real-time status and measurements 4 outlets to connect your PC peripherals EcoControl function helps you save up to 20 % energy compared to previous generation UPSs HID-compliant USB port (cable supplied), for automatic integration with major operating systems (Windows/Mac OS/Linux) Easy to replace battery helps to extend UPS service life.

General specifications

Product Name: Eaton Ellipse Pro UPS
Catalog Number: ELP850IEC
Product Length/Depth: 82 mm
Product Height: 260 mm
Product Width: 285 mm
Product Weight: 7.3 kg
Compliances: CE marked
Certifications:

IEC/EN 62040-1
IEC/EN 62040-2
CE
EAC

UPC: 743172437648

Stock Code: NEP3000

Nova Neptune 3000VA 1800 Watts Line Interactive UPS- Simulated Sine Wave UPS System, Smart RS-232 & USB Communication Ports, Buck and Boost Automatic Voltage Regulation, Discharge, Overcharge And Overload Protection, Recharge time to 90% 4-6 hours; Battery Type 12V/9AH Number Of Batteries 4pcs, Retail Box , 6 month Warranty

Click Here For More Detail

Click Here For a Quick Description

Product Overview:

The Nova Neptune 3000VA 1800 Watts Line Interactive UPS is part of the Tescom series, offering, a cost-effective emergency power solution for home, SME and the corporate environments. Offering automatic voltage regulation, overcharge & overload protection and adequate time to save and systematically power off sensitive computer and electronic equipment. The “plug and play” units are suited to support PC’s, routers, laptops, switches, alarm systems, electronic gas igniters and emergency lighting (LED) The range offers Smart RS-232 & USB Interfaces and supports Windows 95/98/NT/2000/XP, Novell and Linux.

Features:

• Microprocessor control guarantees high reliability
• Equipped with buck and boost (Automatic Voltage Regulation) AVR to stabilise input voltage
• Built-in DC start function enables UPS to be started up without AC power
• Smart RS-232 & USB communication ports with free software and cable
• Auto charge even though UPS is off
• Auto restart when AC returns
• Basic Modem/phone line surge protection
• Discharge, overcharge and overload protection
• Simulated sine wave
• 10-15 minutes load dependant

Specifications:
• Stock Code: NEP3000
• Description: Neptune 3000VA / 1800 Watts UPS

• Nova Neptune 3000VA 1800 Watts Line Interactive UPS

• Simulated Sine Wave UPS System
• Recharge time to 90% 4-6 hours
• Battery Type & Number 12V/9AH x 4pcs
• Retail Box
• 6 month Warranty

Stock Code: 5E2000IUSB

Eaton 5E 2000VA 1200Watts Line Interactive USB UPS, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Eaton 5E 2000VA 1200Watts Line Interactive USB UPS, Retail Box , 1 year Limited Warranty

Product Overview
The Eaton 5E 2000VA 1200Watts USB UPS is an essential line interactive UPS that provides cost effective and reliable power protection against power outages and bad power quality with the Automatic Voltage Regulation (AVR) built-in on this unit. Avoid back door damages coming through your phone lines as the Eaton 5E 2000VA 1200Watts USB models are equipped with data line surge protection (Internet/Tel/Fax).Thanks to its small size the 5E can be installed easily either in a business environment or at home.

Ideal for protecting:
• Desktop PC's , Network Workstations
• NAS, internet access point,
• LED Televisions and CCTV Digital Video Recorders
• Point Of Sale terminals , business telephone systems

Highlights
•Work through under & overvoltage without wasting battery thanks to Automatic Voltage Regulation (AVR)
•Rely on batteries anytime : 5E batteries are permanently recharged (even when off) and UPS can start without mains (Cold-start)
•Avoid back door damages coming through phone lines : 5E USB models are equipped with data line surge protection (Internet/Tel/Fax)
•Plug easily any equipment to the UPS (PC, HD TV, internet gateway,…)
•Install 5E anywhere thanks to its small size
•Easily manage your UPS from your PC

Stock Code: IVR-2400LBKS

Mecer Modified Sine Wave 24VDC 1440W 2400VA Inverter, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Mecer Modified Sine Wave 24VDC 1440W 2400VA Inverter, Retail Box , 1 year Limited Warranty

Description

PLEASE NOTE: Requires 2 x 12V deep cycle batteries. Batteries not included.

Mecer has been one of South Africa's top-selling PCs over the past two decades. Mustek's ongoing interaction within the international IT industry has ensured that Mecer has remained a techno-leader at the forefront of technology.

Mecer 2400VA, 1440W, 24V DC-AC Inverter with LCD Display and Socket for for Optional Solar Power Module (Solar Requires EXT-SCC-2400LBKS [search:EXT-SCC-2400LBKS]). *Cables are included to connect to the battery, lx cable to connect to a South African 3pin wall socket is included. Requires 2x 12V deep cycle batteries *Please take note of connection: Connect RED cable to (+) on battery and the (+) on the unit, and BLACK cable to (-) on battery and the (-) on the unit. Place cable lug directly onto the battery terminal first, follow up with the washer and then the lock washer, and then the nut. Do not put a washer between the battery terminal and cable. Connect the positive cable first. Follow instructions in manual.

FAQ:

Does this product function like a ups?

Yes, it does function similar to a UPS, without the constant beeping.

Can I have everything connected to it and as soon as electricity goes then it'll power up from batteries and when electricity resumes it'll get charged automatically?

Yes, you have 220V outlets, and you can leave everything plugged in. When power goes out, everything continues to work without interruption.

Stock Code: EG003PB

Solarix Power Storage Box - Modified Sine Wave, Rated Power 200w, 1x12V Sealed Lead Acid Battery 30Ah, AC Output Voltage 220V, 3x DC Output 12V/3A , 4x USB 5V Outputs 1x 12V Car Boost Start Jumper Output , Net Weight 9kg, Colour Orange , Retail Box , 6 month Warranty

Click Here For More Detail

Click Here For a Quick Description

Solarix Power Storage Box- Modified Sine Wave, Rated Power 200w, 1x12V Sealed Lead Acid Battery 30Ah, AC Output Voltage 220V, 3x DC Output 12V/3A , 4x USB 5V Outputs 1x 12V Car Boost Start Jumper Output , Net Weight 9kg, Colour Orange , Retail Box , 6 Months Warranty

Product Overview

The Solarix Power Storage Box is the latest product designed especially for load shedding to keep your electronic and electrical devices running during power outages, it equipped with a number of outputs allowing you to power up what you need to and stay connected for about 8 hours with some of the devices connected to this power storage box with a rechargeable 12V Sealed Lead Acid Battery 30Ah that is included, It is ideal for use on Laptops Computers, LED lights, Electrical fans and also provide power backup to all types of DC power equipment such as Routers , Modems , Decoders , VOIP Phone Systems , Surveillance System, Alarm System And Many Critical Telecommunications Equipment. The USB ports can be used to charge or power up Mobile Phones, Tablets, Cameras, Portable Speakers Etc. This unit can be charged through a standard AC outlet or with Solar panels connected to the device. It is perfect for power outages, home emergencies, outdoor activities, picnics, field parties, parades, road trips, camping, boating, urban markets, beach days, emergency relief and rescue, etc.

Please Note: Solar panels are not included with this package and must be purchased separately

Highlights

• Solarix Power Storage Box 200w

• Modified Sine Wave

• 1x Rechargeable 12V Sealed Lead Acid Battery 30Ah

• 1x AC Output Voltage 220V Rated Power 200w

• AC Output Frequency 50Hz

• 3x DC 12V with 36W Power Outputs

• 4x USB 5V outputs (1.0A x2 / 2.1A x2)

• 1x 12V Automotive Jumper Station

• LCD Display Battery Capacity, Battery Voltage

• LED Indicator USB Output Status, AC Charge Status

• 1x AC / DC 14.4V 4A Charging Adaptor Included

• 1x DC LED Light Included

• 1x Car Jumper Lead Included

• Built- In Carry Convenient Carry Handle

Stock Code: 5E1500IUSB

Eaton 5E 1500VA 900Watts Line Interactive USB UPS, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Eaton 5E 1500VA 900Watts Line Interactive USB UPS, Retail Box , 1 year Limited Warranty

Product Overview
The Eaton 5E 1500VA 900Watts USB UPS is an essential line interactive UPS that provides cost effective and reliable power protection against power outages and bad power quality with the Automatic Voltage Regulation (AVR) built-in on this unit. Avoid back door damages coming through your phone lines as the Eaton 5E 1500VA 900Watts USB models are equipped with data line surge protection (Internet/Tel/Fax).Thanks to its small size the 5E can be installed easily either in a business environment or at home.

Stock Code: APEX2000(LED)

Tescom APEX 2000VA, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Tescom APEX 2000VA, Retail Box, 1-year Limited Warranty

Product Overview:

The Apex UPS’s are an entry level cost effective solution, rated 2000VA, and is specifically for use with 1, 2 or 4 PC’s respectively and are designed to provide enough time for an orderly shutdown.

Highlights:

• Microprocessor control guarantees high reliability

• Equipped with boost and buck A VR to stabilize input voltage

• Built-in DC start function enables UPS to be started up without AC power

• Smart RS-232 communication port with free software and cable

• Green power function for energy saving

• User-replaceable battery design

• Auto charge even though UPS is off

• Auto restart when AC returns

• Modem/phone line surge protection

• Discharge, overcharge and overload protection

Specifications:

Product Code: APEX2000(LED)

Description: Tescom Apex 2000VA UPS

VA Rating 2000VA

Watt Rating 1200W

Input Voltage 230VAC

Input Voltage Range 140-300VAC

Output Voltage 230VAC

Output Frequency 50Hz

Output Waveform Simulated Sinewave

Stock Code: GUP100W

Gizzu 100w 46WH 14400mAh Mini POE DC UPS - Black, Input voltage: 100-240Vac, 100W Power Output, 46Wh Total Watt Hours, Battery Capacity: 14400mAh, Dual USB Ports, Compatible Most Routers, Intelligent Protective Design, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Product Overview

The Gizzu 100w Mini DC 46Wh UPS is simple to install and allows you to power various devices during a power outage. With multiple-voltage DC outputs, this UPS can power both your Router and Optical Network Unit (ONU) so you can continue browsing the web, working online, or streaming. CCTV cameras and VoIP phones can also be connected and powered via the Gigabit Power Over Ethernet(POE) port. Charge mobile devices such as cell phones and tablets via USB. Featuring 8 high-capacity Lithium-ion (14400mAh) LifeP04 batteries with safety protocols such as over-charge, over-discharge, and short circuit protection.

Features
• Power Your Router And ONU(Optical Network Unit) During Power Outages
• Keep Your Mobile Devices Charged With Dual USB Ports
• 46Wh High-Capacity Lithium-Ion Lifep04 Batteries
• Power Your CCTV Cameras And VoIP Phones With Gigabit POE
• Compatible With A Wide Range Of Routers
• Intelligent Protective Design With Over-Charge, Over-Discharge, And Short Circuit Protection

Specifications:
• Stock Code GUP100W
• Description Gizzu 100w 46Wh 14400mAh Mini POE DC UPS
• Input voltage: 100-240V AC
• DC Output Voltage:
• 5V + USB x2 (2A)
• 1x 24/48V (POE 1G) (0.65A)
• 1x 9V/12V (Selectable) (3A)
• 5x 12V (5A)
• Power Output: 100W
• Battery Capacity: 14400mAh
• Battery Information: 1800mAh x8 (Lithium-Ion LifeP04)
• Total Watt Hours: 46Wh
• Estimated Recharges (Single device connected):
• Smart Phone(3500mAh): 5
• Tablet (7000mAh): 2.5
• Headlamp (2200mAh): 8
• Estimated Run Time (Single device connected):
• ONU(3W): 15hrs
• Router(10W): 4.6hrs
• CCTV Cameras (10W): 4.6hrs
• VoIP Phone(7W): 6.5hrs
• Dimensions: 26.3 x 15.6 x 4 cm
• Weight: 900g

What’s In The Box:
• Gizzu 100W Mini DC 46Wh UPS – Black x1
• 1m Ac Power Cable x1
• 1m 2.5mm DC Power Cable x2
• 30cm DC Splitter Cable x1
• 5.5 x 2.1mm DC Adapter x1
• 4 x 1.7mm DC Adapter x1
• 3.5mm x 1.35mm DC Adapter x1
• User Manual x1

Stock Code: 5E650IUSB

Eaton 5E 650VA 360Watts Line Interactive USB UPS, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Eaton 5E 650VA 360Watts Line Interactive USB UPS, Retail Box , 1 year Limited Warranty

Product Overview
The Eaton 5E 650VA 360Watts USB UPS is an essential line interactive UPS that provides cost effective and reliable power protection against power outages and bad power quality with the Automatic Voltage Regulation (AVR) built-in on this unit. Avoid back door damages coming through your phone lines as the Eaton 5E 650VA 360Watts USB models are equipped with data line surge protection (Internet/Tel/Fax).Thanks to its small size the 5E can be installed easily either in a business environment or at home.

Ideal for protecting:
• Desktop PC, Network Workstations
• NAS, internet access point,
• LED Television and CCTV Digital Video Recorders
• Point of sales, business telephone system

Stock Code: GUDP36W

Gizzu GUDP36W Black 8800mAh Mini Dual DC UPS , Black- Input Voltage 100~240Vac/50-60Hz, 4x High Capacity Lithium-Ion Batteries 2200mAh , Dual-Voltage DC Outputs, Intelligent Protective Design, Smart Chip Control, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Gizzu GUDP36W Black 8800mAh Mini Dual DC UPS , Black- Input Voltage: 100~240Vac/50-60Hz, 4x High Capacity Lithium-Ion Batteries 2200mAh , Dual-Voltage DC Outputs, Intelligent Protective Design, Smart Chip Control, Retail Box , 1 year Limited Warranty

Product Overview
The Gizzu Mini 8800mAh Dual-voltage DC UPS allows you to power various devices from IP cameras to cordless home phones and routers. It features 4 high capacity lithium-ion batteries for a total of 8800mAh battery power capacity for all your charging needs. Power your CPE (Fibre Box) and Router from one device thanks to dual-voltage DC outputs. For extra safety it also features an intelligent protective design which includes Over-Charge, Over-Discharge and Short Circuit Protection.

Features:
• 8800mAh Dual-voltage DC UPS
• 4X High Capacity Lithium-Ion Batteries
• Dual-voltage DC1 and DC2 Outputs
• Voltage Selection
• Intelligent Protective Design
• Smart Chip Control

Specifications
• Stock Code GUDP36W
• Description Gizzu GUDP36W Black 8800mAh Mini Dual DC UPS
• Product Type Dual-Voltage DC Outputs Mini 8800mAh DC UPS
• Input voltage: 100~240Vac/50-60Hz
• DC1 and DC2 Interface Output Voltage: 5, 9, 12Vdc, Output Current: 5V, 9V, 12V/3A
• Battery: 2200mAh x 4 (Lithium-Ion)
• Dimensions: 18.2 x 10.7 x 3.2 cm
• Weight: 460 g

What’s In The Box:
• GIZZU Mini 8800mAh Dual-voltage DC UPS – Black x1
• AC Power Cable x1
• DC output Cable x2
• User Manual x1

Stock Code: CM5048

Solarix Solar Charger Controller 24/48V 60A - solar controller charge for home use, 60A 24V/48V ,LCD display solar panel ,Product size(mm) 130 mm×188 mm×62 mm, Retail Box , No warranty

Click Here For More Detail

Click Here For a Quick Description

Solarix Solar Charger Controller 24/48V 60A - solar controller charge for home use, 60A 24V/48V ,LCD display solar panel ,Product size(mm) 130 mm×188 mm×62 mm, Retail Box , No warranty

Features:

Image of LCD graphic symbol
Simple button operation
Automatic Identification System Voltage level
Intelligent PWM charge mode
Automatic Temperature Compensation
Adjustable charge-discharge control parameters
Settable Operating mode of Load hours
Accumulated function of charge and discharge Ampere
Remote monitoring and control function (custom)
Battery reverse-discharge protection
Battery reverse-discharge protection
Battery reverse connection protection
Overload, Short Circuit Protection

You can View and Set the Parameters:

Battery Voltage
The load on/off control
Environment Temperature
Solar Panel charging current
Load discharging current
Accumulated charging power (Ah) by solar panel and back to zero
Accumulated discharging power (Ah) by Load and back to zero
Low Voltage Disconnection Protection
Low Voltage Reconnection
High Voltage Disconnection

Three Load Working Mode:

24H—Normal Mode, in case of no fault state of the load is always in power.
1H~23H—Light Control with Time Control Mode, Load power after dark, and close the load according to the timer setting.
0H—Light Control Mode, Load on after dark, turn off the load after drawn.

Technical Data:

Stock Code- CM5048
Description - Solarix Solar Charger Controller 24/48V 60A
Rated current: 40A,50A
Rated voltage: 48V
Maximum voltage of solar panel: ≤100V
Float voltage: 54.8V
Low Voltage Disconnection: 42.8V
Low Voltage Reconnection: 50.4V
No load loss: <30mA
Loop voltage drop: ≤200mV
Charging mode: PWM Mode
Temperature compensation: -4mV/Cell/℃
Installation cable area: >3# AWG (<25mm2)
Operating temperature: -20℃~50℃
Storage temperature: -30℃~70℃
Humidity Requirement: ≤90%, No Condensation
Size: 130mm×188mm×62mm
Mounting hole spacing: 98 mm×178 mm --Φ5
Weight: 590g
Notes: Model suffix“Z” represent automatic identify system voltage level,“T”represent controller with remote monitoring

Stock Code: GU30W

Gizzu GU30W 30w 32wh 8800mah Mini DC UPS, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Gizzu GU30W 30w 32wh 8800mah Mini DC UPS - Black, Retail Box , 1 year Limited Warranty

Product Overview

The Gizzu 30W Mini DC 32Wh UPS is simple to install and allows you to power various devices during a power outage. With multiple-voltage DC outputs, this UPS can charge mobile devices such as cell phones and tablets via USB. It also features 8800mAh of high-capacity lithium-ion batteries with safety protocols such as over-charge, over-discharge, and short circuit protection.

FEATURES

• Power your Router and ONU (Optical Network Unit) during power outages
• Keep your mobile devices charged with the USB port
• 32Wh High-capacity lithium-ion batteries
• Power your CCTV cameras
• Compatible with a wide range of devices
• Intelligent protective design with over-charge, over-discharge, and short circuit protection

SPECIFICATIONS:
• Stock Code GU30W
• Description Gizzu GU30W 30w 32wh 8800mah Mini DC UPS - Black
• Input Voltage: 100 - 240V AC
• DC Output Voltage:
• 5V + USB x 1 (2A)
• 1 x 9V/12V (selectable) (2A)
• 4 x 12V (2A)
• Power Output: 30W
• Battery Capacity: 8800mAh
• Battery Information: 2200mAh x 4 (Lithium-ion)
• Total Watt Hours: 32Wh
• Estimated Run Time:
• ONU(3W): 10.6 hrs
• Router (10W): 3 hrs
• CCTV Camera (10W): 3 hrs
• Product Dimensions: 18.6 x 11 x 3.3 cm
• Product Weight: 430g

Stock Code: NEP700

Nova Neptune 700VA / 360 Watts UPS; Recharge time to 90% 4-6 hours; Battery Type & Number 12V/7AH x 1pc, Retail Box , 3 month Warranty

Click Here For More Detail

Click Here For a Quick Description

Neptune 700VA / 360 Watts UPS; Recharge time to 90% 4-6 hours; Battery Type & Number 12V/7AH x 1pc, Retail Box , 3 month Warranty

Product Overview:

The NOVA NEPTUNE 700VA is part of our entry level series offering, a cost-effective emergency power solution for home, SME and the corporate environments. Offering automatic voltage regulation, overcharge & overload protection and adequate time to save and systematically power off sensitive computer and electronic equipment. The “plug and play” units are suited to support PC’s, routers, laptops, switches, alarm systems, electronic gas igniters and emergency lighting (LED) The range offers Smart RS-232 & USB Interfaces and supports Windows 95/98/NT/2000/XP, Novell and Linux.

Features:

• Microprocessor control guarantees high reliability
• Equipped with buck and boost (Automatic Voltage Regulation) AVR to stabilise input voltage
• Built-in DC start function enables UPS to be started up without AC power
• Smart RS-232 & USB communication ports with free software and cable
• Auto charge even though UPS is off
• Auto restart when AC returns
• Basic Modem/phoneline surge protection
• Discharge, overcharge and overload protection
• Simulated sinewave
• 10-15 minutes load dependant

Specifications:
• Stock Code: NEP700
• Description: Neptune 700VA / 360 Watts UPS
• Recharge time to 90% 4-6 hours
• Battery Type & Number 12V/7AH x 1pcs
• Retail Box
• 3 month Warranty

Stock Code: CM6024

Solarix Solar Charger Controller 12/24V 60A -solar controller charge for home use, 60A 12V/24V ,LCD display solar panel ,Product size(mm) 190*160*62mm, Retail Box , No warranty

Click Here For More Detail

Click Here For a Quick Description

Solarix Solar Charger Controller 12/24V 60A -solar controller charge for home use, 60A 12V/24V ,LCD display solar panel ,Product size(mm) 190*160*62mm, Retail Box , No warranty

Product Overview

This controller is a kind of intelligent, multi-purpose solar charge and discharge controller. These serial products adopt customized LCD display screen, which makes the operation on the interface rather convenient. All the controlling parameters can be reset flexibly to satisfy your different needs.

This controller has the following features:

● Visual LCD graphic symbol

● Brief key operation

● Automatic identification system voltage level

● Intelligent PWM charge mode

● Automatic temperature compensation

● Adjustable charge-discharge control parameters

● Settable operating modes of loads

● Accumulated charge and discharge ampere hours

● Remote monitoring function (custom)

● Battery reverse-discharge protection

● Battery low voltage disconnection (LVD)
